Insulation Just Got Better
Let us introduce you to our class leading compressor insulation jacket: EnbiTherm. EnbiTherm provided outstanding thermal and acoustic performance to help you to optimize energy efficiency supporting green initiatives worldwide scale.
One of our key strengths lies in our ability to provide tailored solutions. EnbiTherm can be customized to fit any shape or profile, enabling seamless installation for equipment manufacturers across the globe. This ensures a hassle-free integration process and guarantees maximum effectiveness and performance
When you choose EnbiTherm, you select a transformative approach to compressor insulation solutions. Join us on our mission to forge a more energy-efficient future and experience the Enbi difference firsthand.
The heat pump compressor insulation jacket creates a protective barrier between the compressor and the surrounding environment, which can often be harsh and cold. In doing so, the insulation jacket helps to maintain a consistent temperature around the compressor and prevent heat loss. Additionally, it helps to reduce the amount of noise that the compressor produces during its operation, making it a more comfortable addition to a residential setting. For More information on heat pumps Vs HVAC, read Enbi Group’s expert guide.
Several insulation materials can be used for heat pump compressors, including foam pipe insulation, vinyl barrier, and sound blankets. Each type of insulation has its own benefits and drawbacks, which should be considered when selecting the appropriate type for a given application.
Foam pipe insulation is a cost-effective and easy-to-install option, but it may not be as effective as other types of insulation when it comes to reducing noise. Vinyl barrier insulation is more effective at reducing noise, but it can be more expensive and difficult to install than foam pipe insulation. Sound blankets are a popular option for reducing compressor noise, but they can be bulky and may only fit some sizes and shapes.
Several factors must be considered when selecting the appropriate insulation type for a heat pump compressor. These include the climate in which the system will operate, the level of compressor noise reduction needed, and the insulation cost.
Regarding cost-effective solutions, foam pipe insulation is often popular, as it is relatively inexpensive and easy to install. For industry-standard options, manufacturers such as Brinmar offer compressor noise blankets that provide high-level noise reduction and are specifically designed to fit a variety of compressor types.
Overall, the heat pump compressor insulation jacket is important in ensuring a heat pump system’s efficient and noise-free operation. Homeowners can enjoy the benefits of a comfortable and energy-efficient home by selecting the appropriate insulation type based on the system’s specific needs.
EnbiTherm offer customers significant benefits over non insulated unit. These include:
Noise Reduction
Heat pump compressors can produce high levels of noise, which can be disruptive and pose a health hazard to nearby personnel. EnbiTherm jackets can significantly reduce noise transmission to the surrounding environment. This is particularly beneficial in noise-sensitive environments such as residential areas, hospitals, or office buildings.
Energy Saving
Well designed insulation can significantly reduce the energy consumption of a unit by trapping heat where it needs to be. EnbiTherm’s unique design helps to reduce energy loses saving money and reducing CO2.
Safety and Comfort
Excessive noise can have negative effect on people, especially in built up areas. EnbiTherm jackets solve this by isolating the compressor, the level of noise transmitted to the surrounding environment if greatly reduced. This leads to increased user comfort and safety by eliminating distractions caused by excessive noise.
- Slitting & cutting
- 2D contour cutting
- Flat bed & rotary die cutting
- Laminating
- Drilling
- UR-foams 12-650 kg/m3
- Polyethylene, melamine resin, composite, synthetic EPDM and filter (15-80 ppi) foams
- Heavy layer (bitumen)
- Fleece (non-wovens)
- Self-adhesives
- Foils (PET, copper, fleece, aluminum)
- EPS
Enbi also has the capability to refine materials by laminating special foils and adhesives (for example, PUR-foils, PET, aluminum, copper, conductive coatings). Our material range is based on PUR foams and similar material groups such as:
- PUR-foam from 10 kg/m³ up to 650 kg/m³
- Polyester foam
- Polyether foam
- Polyethylene foam
- Microcellular foam
- Melamine resin foam
- EPDM neoprene rubber, CR-EPDM etc
- Non-woven
- Silicone-rubber
- Homogeneous polyurethanes
- From 45 Sh A up to 95 Sh A
- Low fogging / low emission
- FMVSS 302, UL94, DIN4102
- Temperature range -40 °C to 180 °C
- Oleo phobic and hydrophobic
- Acoustic test (alpha cabin, acoustic impedance)
- Customized product development and engineering support with 50+ years of experience.
Heat pumps are becoming increasingly popular for both heating and cooling homes, and with good reason: they are more efficient than traditional HVAC systems. They can actually save homeowners money in the long run. However, one downside to heat pumps is the noise they can generate, particularly from the compressor. Luckily, several types of heat pump compressor insulation can be used to reduce this noise and increase energy efficiency.
One type of insulation is sound blankets. These are blankets of sound-absorbing material that can be wrapped around the compressor housing to reduce noise levels. They are often made of high-quality fibreglass or other materials that absorb sound waves. Sound blankets are an effective solution for reducing noise, specifically designed to address this problem. They are cost-effective, easy to apply and come in different configurations depending on the model of the heat pump.
Foam pipe insulation is another effective option for heat pump compressor insulation. This type of insulation is made of a special foam material that can be wrapped around the refrigerant lines and other pipes associated with the heat pump system. It helps reduce heat loss, prevent freezing, and dampens sound. This type of insulation is most effective when applied in the correct recommended thickness.
Insulation tape is also a viable option for heat pump compressor insulation. It is a type of adhesive that can cover copper lines and other heat pump system components to reduce noise and prevent heat loss. Insulation tape is designed to be easily applied and is available in different sizes and lengths.
Copper lines are another component that can be insulated to reduce noise levels. Copper pipes often carry refrigerant gases around the heat pump system. Insulating these pipes with the proper insulation materials can significantly reduce noise levels. This type of insulation is most effective when combined with other insulation materials to create a fully insulated system.
In recent years, industry-leading blanket solutions have emerged as an effective solution to reduce noise levels and improve overall energy efficiency in a heat pump system. These blankets are designed to fit snugly around the compressor housing, reducing noise levels significantly. They are often made of high-quality fibreglass or other sound-absorbing materials specifically designed to absorb sound waves while preventing heat loss.
In summary, several heat pump compressor insulation types can be utilized to reduce noise and increase energy efficiency. Whether it is sound blankets, foam pipe insulation, insulation tape, copper lines, or industry-leading blanket solutions, proper insulation can provide benefits such as noise reduction, improved energy efficiency, and increased comfort. It is important to select the right insulation solution that will work best for the particular heat pump model to maximize performance and achieve the desired results.
